TECHNICAL FEATURES - LEGUAN 225

MAX. WORKING HEIGHT

74 ft

MAX. SIDE REACH

37 ft

MAX. LIFT CAPACITY

550 lbs

MAX. PLATFORM HEIGHT

67 ft

All-terrain spider lift with unrivaled performance

INDUSTRY-LEADING all-terrain capabilities, a high-profile track platform and fast driving speeds make the nextgeneration Leguan 225 a perfect choice for even the most demanding environments. The spider lift’s boom is designed to maximize side reach even at high working heights, while intuitive user interface guarantees quick and smooth movements.

Thanks to user-friendly joystick controls, boom operation remains steady, and simultaneous movements become second nature. The Leguan 225’s intelligent features minimise malfunctions and boost efficiency, allowing you to focus on the task at hand. Additionally, the boom is protected from external impacts, falling branches, and sawdust, making the 225 an excellent choice for arborists, construction workers, and other professionals.

TECHNICAL FEATURES

Max. lift capacity 550 lbs (2 persons)
Max. working height 74′
Max. platform height 67′ 3″
Max. side reach 30′ (550 lbs) –
37' (265 lbs)
Transport dimensions, L x W x H 19′ 9″ x 4′ 4″ x 7′ 3″
Platform dimensions 4‘ 4“ x 2’ 6”
Rotation of basket 110º (±55º)
Slewing 440º
Gradeability *) 45% (25º)
Dimensions w/o platform, L x W 17′ 7″ x 4′ 1″
Outrigger support dimensions 13′ 5″ x 13′ 5″
Max. slope for outriggers 25 % (14º)
weight 6,340 lbs
Engine Kubota 21 hp diesel or
110 V / 2.2 kW electric
Drive system: hydraulic tracks
Max. Drive speed 1.9 mph

Standard features

  • Leguan EDX
  • 21 hp Kubota diesel engine
  • Automatic engine RPM control
  • Automatic start-stop function for electric motor
  • Automatic levelling of the outriggers
  • Proportional outreach monitoring system
  • Electric rotation of the platform
  • Home function / Back to work position function
  • JIB-boom with 120-degree operating range
  • USB & USB-C power outlets on platform
  • Battery powered emergency lowering system
  • Lower controls with integrated service display
  • Elevated driving position

Optional features

  • 110 V electric motor + 110 V power outlets on platform
  • Remote control for driving and outriggers
  • LED spot lights for platform
  • Tool trays on platform
  • Outrigger beacons
  • Hose to platform (air/water)
  • Engine heater
  • Non-marking tracks
  • Narrow single person platform
  • Custom colour

Measurements
