Leguan Lifts - Straight to the Point.
LEGUAN LIFTS specializes in designing and manufacturing reliable and technologically advanced self-propelled access platforms. Leguan has a long tradition in this field; the first self-propelled access platform with outriggers was introduced in 1994. Leguan Lifts is part of the fast-growing Avant Tecno Group from Finland.
Every spider lift is designed with extraordinary all-terrain capabilities and robust boom structure, which makes Leguans versatile and fit for any access job. Leguans are built to withstand all climates from the heat and humidity of Florida to the freezing cold winters of Minnesota. In recent years, Leguan Lifts has completely restructured their product selection introducing many unseen features and the most user-friendly interface to date.
- Unrivalled all-terrain capabilities
- Robust boom construction and protected chassis
- Efficient hydraulics for simultaneous multi-boom operation
- Industry-leading side reach and up and over clearance
- Highest standard of safety and user-friendly design
Leguan Lifts -Straight to the point.
Versatile.
Leguan spider lifts are known for their exceptional off-road capabilities, and industry-leading gradeability. Sturdy track or tire chassis with leading ground clearance and travel speeds ensure rapid transitioning through snow or mud. The fuel-efficient combustion engine and silent electric operation makes Leguan a great fit for both inside and outside use, and the compact size makes transportation easy.
Intuitive and user-friendly.
Advanced hydraulic design allows smooth and simultaneous boom movements, which makes it easy to maneuver Leguans in narrow places and maintain distance to walls. The new Leguan spider lifts are equipped with user-friendly features such as automatic leveling that allows effortless outrigger leveling with just a single push of a button, even on challenging terrain.
Next generation features.
Both the safety features and the proportional outreach monitoring system are controlled by a modern PLC that ensures the highest standard of safety combined with unrivalled outreach in all situations. Leguan Lifts lead the way with superior industrial design, numerous technological innovations and smart energy saving functions, which provide Leguans with high resale values over time.
Options.
Leguan spider lifts are always well-equipped and come with many advanced features as standard to ensure the highest efficiency. However, you can equip your own Leguan with many additional features to match the requirements of your line of work or job sites.
Some of the most popular optional features are the outrigger beacons that improve work safety. For the colder climates we recommend engine heater for the diesel engine. Inquire more about the standard and optional features from your local Leguan dealer.
TECHNICAL INFORMATION
MAX. WORKING HEIGHT
74 ft
MAX. SIDE REACH
37 ft
MAX. LIFT CAPACITY
550 lbs
MAX. PLATFORM HEIGHT
67 ft
All-terrain spider lift with unrivaled performance
INDUSTRY-LEADING all-terrain capabilities, a high-profile track platform and fast driving speeds make the next-generation Leguan 225 a perfect choice for even the most demanding environments. The spider lift’s boom is designed to maximize side reach even at high working heights, and a smart control interface guarantees quick and smooth movements.
Thanks to our user-friendly joystick controls, controlling the boom structure is steady and simultaneous movements come naturally. The Leguan 225’s smart features reduce malfunctions and increase efficiency so that you can focus on the project at hand. The boom is shielded from external blows, falling branches and sawdust, making the 225 a great choice for arborists and construction workers alike.
TECHNICAL FEATURES
| Max. lift capacity | 550 lbs (2 persons) |
| Max. working height | 74′ |
| Max. platform height | 67′ 3″ |
| Max. outreach | 29′ 10″ (550 lbs) – 36′ 9″ (265 lbs) |
| Transport dimensions, L x W x H | 19′ 9″ x 4′ 4″ x 7′ 3″ |
| Platform dimensions | 4‘ 4“ x 2’ 6” |
| Rotation of basket | 110º (±55º) |
| Slewing | 360º |
| Gradeability *) | 45% (25º) |
| Dimensions w/o platform, L x W | 17′ 3″ x 4′ 1″ |
| Outrigger support dimensions | 13′ 5″ x 13′ 5″ |
| Max. slope for outriggers | 25 % (14º) |
| weight | 6500 lbs |
| Engine | Kubota 21 hp diesel or 110 V / 2.2 kW electric |
| Drive system: hydraulic | tracks |
| Max. Drive speed | 1.9 mph |
Standard features
- 21 hp Kubota diesel engine
- Automatic engine RPM control
- Automatic start-stop function for electric motor
- Automatic levelling of the outriggers
- Proportional outreach monitoring system
- Electric rotation of the platform
- Home function / Back to work position function
- JIB-boom with 120-degree operating range
- USB power outlet on platform
- Battery powered emergency lowering system
- Lower controls with integrated service display
- Signal horn
Optional features
- 110 V electric motor + 110 V power outlets on platform
- Remote control for driving and outriggers
- LED spot lights for platform
- Tool trays on platform
- Outrigger beacons
- Hose to platform (air/water)
- Engine heater
- Non-marking tracks
- Narrow single person platform
- Leguan special trailer
Measurements
Ask a question.
Download brochure.
MAX. WORKING HEIGHT
62 ft
MAX. SIDE REACH
32 ft
MAX. LIFT CAPACITY
507 lbs
MAX. PLATFORM HEIGHT
56 ft
Robust and steady spider lift with all-terrain capabilities.
LEGUAN 190 is an access platform designed for heavy duty professional and rental use. In the design of the spider lift, special attention has been paid to durability, excellent up-and-over clearance and user-friendly interface. Leguan 190 is the right choice for tree care, painters, construction work and facility maintenance.
High ground clearance and steady, protected tracked (or 4WD) base provide fast and smooth access on rough terrain. All Leguans are designed to be driven safely while standing in the basket to increase efficiency while transitioning on site. Many leading features such as the automatic leveling is standard, but operators can also opt for many optional features such as the extra speed for the fastest driving speed in the market.
TECHNICAL FEATURES
| Max. lift capacity | 507 lbs (2 persons) |
| Max. working height | 62’ 4” |
| Max. platform height | 55’ 9” |
| Max. outreach | 26‘ 7” (507 lbs) – 32’ 2” (265 lbs) |
| Transport dimensions, L x W x H | 16‘ 9“ x 4‘ 4“ x 6‘ 11“ |
| Platform dimensions | 4‘ 4“ x 2’ 6” |
| Rotation of basket | 90º (±45º) |
| Slewing | 360º |
| Gradeability *) | 40% (22º) |
| Dimensions w/o platform, L x W | 14’ 7” x 4’ 1” |
| Outrigger support dimensions | 11’ 10” x 12’ 1” |
| Max. slope for outriggers | 21% (12º) |
| weight | 5,865 lbs |
| Engine | Kubota 14 hp diesel or 110 V / 2.2 kW electric |
| Drive system: hydraulic | 4WD / tracks |
| Max. Drive speed | 1.6 mph or 3.2 mph |
*) Operator in basket
Standard features
- 14 hp Kubota diesel
- Automatic engine RPM control
- Automatic leveling of the outriggers
- Proportional outreach monitoring system
- Electric rotation of the platform
- JIB-boom with 120 degree operating range
- 12 V power outlet on platform
- Electric and hand pump powered emergency lowering
- Controls on the ground with integrated service display
- 12 V booster points
Optional features
- 110 V electric motor + 110 V power outlet on platform
- Extra drive speed (max. 3.2 mph)
- Remote control for driving and outriggers
- Platform control panel lighting and LED spotlights
- Tool trays on platform
- Outrigger beacons
- Hose to platform (air/water)
- Signal horn
- Engine heater
- Larger plates for outriggers
- Non-marking tracks / tires
- Narrow single person platform
Measurements
Ask a question.
Download brochure.
