Property maintenance

Sand/salt spreader

More images

plus

Property maintenance

Sand/salt spreader

The new sand/salt spreaders are equipped with a new type spreading system: a hydraulically operated pendulum spreading plate which moves horizontally and spreads the material. Spreading plate height can be adjusted following the material type, which allows the spreading of gravel as well as finer sand and salt. A blocking plate kit, available as an option, is necessary when spreading salt and fine sand (prevents the material from falling out by itself).

The unit spreads about 200-300 mm wider than the spreader’s own width, and thanks to the smooth movement of the spreading plate there is no risk of causing damage to the objects around (parked cars, buildings, etc.). Spreading speed can be adjusted steplessly with a flow divider valve.

The spreader is front mounted as standard and can be tilted down so that it can be loaded like a normal bucket. The rear mounting is possible on Avant 700 series, on the optional self-loading hydraulic rear lift A427547. In this case, the loader must be equipped with the optional rear auxiliary hydraulics outlet and attachment control switch pack for rear-mounted attachments. Rear lights are also available as an option.

  • Pendulum type sand/salt spreader spreads 200-300 mm wider than the spreader’s own width

  • Two models

  • Adjustable spreading amount and speed

  • Can spread gravel, sand, and salt

  • Front-mounted as standard – rear mounting possible on Avant

    528/530 & 600, 700 and 800 series

Technical data

Model 900 1200
Spreding widht

1000-1100 mm

1400-1500 mm

Volume

215 l 

430 l

Total width

940 mm

1320 mm

Length

1140 mm

1140 mm

Height

550 mm 

550 mm

Weigth

121 kg

194 kg

Recommended aux. hydr. oil flow

15-30 l/min

15-30 l/min

Max. aux. hydr. oil flow

35 l/min / 225 bar

35 l/min / 225 bar

Product no.

A427150

A424325



OPTIONS

A429245 Blocking plate kit for spreader 900
A429247 Blocking plate kit for spreader 1200
A429959 Rear lights
A37315 Mounting plate for 200 series, increases tilting angle by 30°

A433267

Rear mounting plate 528/530/600 serie

A441613

Rear mounting plate 700 series

A441666

Rear mounting plate 800 series

A427547

Hydraulic rear lift 700 series

A438490

Hydraulic rear lift 800 series

SAMHÆF MODEL

Compatible
Adaptable
Incompatible
Model
220
225
225LPG
313S
320S
420 & 423
520
523
525LPG
528
530
R20
R28
R35
630
635
640
735
745
750
755i
760i
850
860i
e5
e6
900
1200
